Filter and Firewall

This section provides details about firewall mechanisms.

"Packet Filtering"

"Stateful Inspection"

This is a simple firewall solution that is usually implemented on devices like

routers that filter packets. The packet-headers are inspected when going through

the firewall. Packets are analyzed against a set of rules. Depending on these

rules, the packet is either accepted or denied.

Once a match is found, the rule action is obeyed. The rule action could be to drop

the packet, to forward the packet, or even to send an ICMP message back to the

originator. Only the first match counts, as the rules are searched in order. Hence,

the list of rules can be referred to as a ``rule chain''. On match, the specified action

is taken. Typical actions are deny/ allow / drop/ reject packets or reset connection.

This is an advanced implementation of packet filtering that inspects packets at

higher network layers, up to the application layer. Such filters interpret transport-

level information (such as TCP and UDP headers) to analyze and record all

current connections. This process is known as stateful inspection.

A stateful packet filter records the status of all connections and allows only those

packets that are associated with a current connection. Information traveling from

inside the firewall to the outside is monitored for specific defining characteristics.

The incoming information is then compared to these defining characteristics and

upon a reasonable match, the information is permitted, else it is denied.

When a computer in the protected network initiates a connection with an external

server, the stateful packet filter allows the server's response packets into the

protected network. When the original connection is closed, however, the packet

filter will block all further unsolicited packets from the untrusted zone. Stateful

firewalls are also known as "dynamic" packet filters.

OA-700 supports stateful and stateless inspection. By default, OA-700 firewall is
