Provisioning Summary

To create a data path from the GigE SM port on the Total Access 5000 to an Ethernet port on
the NetVanta 8044, complete the following procedure:
1. Provision the GE 8‐Port Line Module.
2. Configure the subtended host information.
3. Create an Ethernet Virtual Circuit (EVC) at the Total Access 5000 that connects the
4. Log on to the NetVanta 8044.
5. Create the EVC at the NetVanta 8044.
6. Create a map at the NetVanta 8044 that informs the unit to switch data from a given User
7. Provision policers in the NetVanta 8044.
8. Provision MAC Address Limiting and Aging.
9. Disable any unused interfaces.
65K510DEP08-1A
For more information, refer to "Provision the GE 8‐Port Line Module" on page 7‐4.
For more information, refer to "Configure Subtended Host Information" on page 7‐5.
Gigabit Ethernet port of the default ethernet interface.
This creates the mapping of the S‐tagged data. This accomplishes the following:
• The GigE SM knows where to send the tagged traffic coming in from the default
ethernet interface
• The GigE SM pushes the available tags to each GE 8‐Port LM and to each NetVanta
8044 for the local NetVanta 8044 provisioning
For more information, refer to "Create an EVC Cross Connect" on page 7‐6.
For more information, refer to "Log On to the NetVanta 8044" on page 7‐8.
The EVC is a connection between two physical ports.
For more information, refer to "Create an EVC" on page 7‐9.
to Network Interface (UNI), at a minimum, to a particular EVC, and vice versa.
For more information, refer to "Create an EVC Map" on page 7‐12.
For more information, refer to "Provision Policers in the NetVanta 8044" on page 7‐14.
For for more information, refer to "Provision MAC Address Limiting and Aging" on
page 7‐17.
For more information, refer to "Disable Unused NetVanta 8044 Interfaces" on page 7‐18.
Section 7, EoF Provisioning - Provisioning Summary
