Provisioning Summary

To create a data path from the GigE SM port on the Total Access 5000 to an Ethernet port on
the NetVanta 800, complete the following:
1. Provision the DS3 EFM 4‐Port or DS3 EFM 3‐Port Line Module.
2. Create an EFM bonding group at the GigE SM that bonds a set of DS3 ports on the DS3
3. Create an Ethernet Virtual Circuit (EVC) at the Total Access 5000 that connects the EFM
4. Log on to the NetVanta 800.
5. Create the EVC at the NetVanta 800.
NOTE
• Multiple EVCs can be created for a given EFM group.
• For the NetVanta, the shelf is always 1 and the slot is always zero.
6. Create a map at the NetVanta 800 that informs the unit to switch data from a given User
7. Provision MAC Address Limiting and Aging.
8. Disable any unused interfaces.
65K510DEP08-1A
For more information, refer to "Provision the Line Module" on page 6‐4.
EFM line module together.
The bonding group acts as the data flow access point to the NetVanta 800 and is the path
down which the management configuration is pushed.
For more information, refer to "Create an EFM Bonding Group" on page 6‐6.
group to the Gigabit Ethernet port of the GigE SM.
This creates the mapping of the S‐tagged data. This accomplishes the following:
• The GigE SM knows where to send the tagged traffic coming in from the gigabit
network port
• The GigE SM pushes the available tags to each EFM bonding group and to each
NetVanta 800 for the local NetVanta 800 provisioning
For more information, refer to "Log On to the NetVanta 800" on page 6‐16.
The EVC is a logical connection point into the EFM group.
For more information, refer to "Create an EVC" on page 6‐17.
to Network Interface (UNI), at a minimum, to a particular EVC, and vice versa.
For more information, refer to "Create an EVC Map" on page 6‐20.
For for more information, refer to "Provision MAC Address Limiting and Aging" on
page 6‐27.
For more information, refer to "Disable Unused NetVanta 800 Interfaces" on page 6‐28.
