HandyTone-486 User Manual
HandyTone-486 Analog Telephone Adaptor is an all-in-one VoIP integrated device designed to be a
total solution for networks providing VoIP services.
The HandyTone-486 VoIP functionalities are available via a regular analog telephone.
The following photo illustrates the appearance of a HandyTone-486.
Top View
BUTTON
RED LED
GREEN LED
Interconnection Diagram of the HandyTone-486:
PSTN

Installation

2
Internet ADSL/Cable
Modem Ethernet
WAN
LINE
LAN
PC PC PC
5
Side Views
RJ45
RJ11
10M Ethernet
Telephone
LAN - WAN
(Phone)
RJ11
Phone Line
(Line)
PHONE
Grandstream Networks, Inc.
+5V/1200mA
Analog Phone
Cordless Phone
Fax
