8 Servicing the RAID on Motherboard (ROMB)
Components

Installing and Removing the Intel

Key
Installing the Intel
®
The optional Intel
board.
1. Observe the safety precautions, warnings, and cautions described in
5.
2. Turn off all peripheral devices connected to the system.
3. Power down the system and unplug both AC power cords.
4. Remove the top cover. For instructions, see "Removing the Top Cover", page 144.
5. Remove the memory board air baffle or the memory board from Slot C. For instructions, see
"Cold Removal of Memory
6. If a PCI card is in Slot 7, remove it to expose the Intel
instructions on removing a PCI card, see
7. Remove the new Intel
8. Insert the Activation Key into the socket on the main board and push it into the socket until it is
below the two retaining clips. See letter "C" in Figure 99.
NOTE
Letters "A" and "B" in Figure 99 show the installation of the RAID DIMM.
The RAID DIMM is also required to activate ROMB. For instructions on
installing the RAID DIMM, see
190
®

RAID Activation Key

RAID Activation Key provides access to the RAID functionality on the main
Board", page 165.
®
RAID Activation Key from its package
"Installing the RAID DDR2-400
®
RAID Activation
®
RAID Activation Key holder. For
"Removing a Non-Hot-Plug PCI
"Safety Information", page
Card", page 154.
DIMM".
