VLT® AutomationDrive EZ FC 321
Programming Guide
Parameter 5-95 Pulse Out #29 Bus Control
Table 339: Parameter 5-95 Pulse Out #29 Bus Control
5-95 Pulse Out #29 Bus Control
Default value: 0%
Conversion index: -2
Set the output frequency transferred to output terminal 29 when the terminal is configured as [45] Bus Controlled in parameter 5-63
Terminal 29 Pulse Output Variable.
Parameter 5-96 Pulse Out #29 Timeout Preset
Table 340: Parameter 5-96 Pulse Out #29 Timeout Preset
5-96 Pulse Out #29 Timeout Preset
Default value: 0%
Conversion index: -2
Set the output frequency transferred to output terminal 29 when the terminal is configured as [48] Bus Ctrl Timeout in parameter
5-63 Terminal 29 Pulse Output Variable and a timeout is detected.
Parameter 5-97 Pulse Out #X30/6 Bus Control
Table 341: Parameter 5-97 Pulse Out #30/6 Bus Control
5-97 Pulse Out #30/6 Bus Control
Default value: 0%
Conversion index: -2
Set the output frequency transferred to output terminal X30/6 when the terminal is configured as [45] Bus ctrl. in parameter 5-66
Terminal X30/6 Pulse Output Variable.
Parameter 5-98 Pulse Out #X30/6 Timeout Preset
Table 342: Parameter 5-98 Pulse Out #30/6 Timeout Preset
5-98 Pulse Out #30/6 Timeout Preset
Default value: 0%
Conversion index: -2
Set the output frequency transferred to output terminal X30/6 when the terminal is configured as [48] Bus Ctrl Timeout in parameter
5-66 Terminal X30/6 Pulse Output Variable and a timeout is detected.

4.7 Parameter Group 6-** Analog In/Out

4.7.1 6-0* Analog I/O Mode

The analog inputs can be allocated to be either voltage (0 to ±10 V) or current input (0/4–20 mA).
Thermistors may be connected to either an analog or a digital input.
Danfoss A/S © 2021.08
Parameter type: Range, 0 - 100%
Data type: N2
Parameter type: Range, 0 - 100%
Data type: Uint16
Parameter type: Range, 0 - 100%
Data type: N2
Parameter type: Range, 0 - 100%
Data type: Uint16
N O T I C E
Parameter Descriptions
Setup: All setups
Change during operation: True
Setup: 1 setup
Change during operation: True
Setup: All setups
Change during operation: True
Setup: 1 setup
Change during operation: True
AU373327181955en-000101 / 130R1208 | 179
