IDLE clocks are inserted between the adjacent channels for a total of three IDLE clocks. When channels are
skipped, one more IDLE clock is inserted for each unselected channel. Therefore, there are 3 (inter-channel
IDLE) + 2 (skipped channels) = 5 IDLE clocks between the fundamental and HAE_H3_INDX transfers.
Results Memory
The results memory is organized by the fundamental and 12 harmonic indexes. Each of the 13 potentially analyzed
frequencies has eight locations dedicated to store various power quality measurements. Each frequency is offset from
the next by eight locations.
The HAE Results Memory figure shows the results memory contents.
Figure 49-6: HAE Results Memory
RAM Parity Protection
HAE Results Upper Byte ID
The HAE results are stored in a 24-bit wide memory as shown in
When the system bus moves the results into memory, the HAE hardware appends a unique CHANNEL:INDEX
identifier to the upper byte of each results location. The intent of the ID byte is to help in data parsing of HAE
results.
The 32-bit appended result is as follows:
ADSP-SC58x/ADSP-2158x SHARC+ Processor Hardware Reference
INDEX 0 1
GROUP OFFSET
FUNDAMENTAL 0x00 F_IRMS F_VRMS
H1_INDEX 0x08 H1_IRMS H1_VRMS
H2_INDEX 0x10 H2_IRMS H2_VRMS
H3_INDEX 0x18 H3_IRMS H3_VRMS
H4_INDEX H4_IRMS
0x20 H4_VRMS
H5_INDEX 0x28 H5_IRMS
H5_VRMS
H6_VRMS
H6_INDEX 0x30 H6_IRMS
H7_INDEX 0x38 H7_IRMS H7_VRMS
H8_INDEX 0x40 H8_IRMS H8_VRMS
H9_INDEX 0x48 H9_IRMS H9_VRMS
H10_INDEX 0x50 H10_IRMS H10_VRMS
H11_INDEX 0x58 H11_IRMS H11_VRMS
H12_INDEX 0x60 H12_IRMS H12_VRMS
2 3 4 5
F_ACT F_REACT F_APP F_PF
H1_ACT H1_REACT H1_APP H1_PF
H2_ACT H2_REACT H2_APP H2_PF
H3_ACT H3_REACT H3_APP H3_PF
H4_ACT H4_REACT H4_APP H4_PF
H5_ACT H5_REACT H5_APP H5_PF
H6_ACT H6_REACT H6_APP H6_PF
H7_ACT H7_REACT H7_APP H7_PF
H8_ACT H8_REACT H8_APP H8_PF
H9_ACT H9_REACT H9_APP H9_PF
H10_ACT H10_REACT H10_APP H10_PF
H11_ACT H11_REACT H11_APP H11_PF
H12_ACT H12_REACT H12_APP H12_PF
Results Memory.
HAE Architectural Concepts
6 7
N/A N/A
H1_IHDN H1_VHDN
H2_IHDN H2_VHDN
H3_IHDN H3_VHDN
H4_IHDN
H4_VHDN
H5_IHDN H5_VHDN
H6_IHDN H6_VHDN
H7_IHDN H7_VHDN
H8_IHDN H8_VHDN
H9_IHDN H9_VHDN
H10_IHDN H10_VHDN
H11_IHDN H11_VHDN
H12_IHDN H12_VHDN
