Table A-18: ADSP-SC58x CSPFT1 MMR Register Addresses (Continued)
Memory Map- Register Name
ped Address
0x31107FF8 CSPFT1_CID2
0x31107FFC CSPFT1_CID3
Table A-19: ADSP-SC58x DAI0 MMR Register Addresses
Memory Map- Register Name
ped Address
0x310C90C0 DAI0_CLK0
0x310C90C4 DAI0_CLK1
0x310C90C8 DAI0_CLK2
0x310C90CC DAI0_CLK3
0x310C90D0 DAI0_CLK4
0x310C90D4 DAI0_CLK5
0x310C9100 DAI0_DAT0
0x310C9104 DAI0_DAT1
0x310C9108 DAI0_DAT2
0x310C910C DAI0_DAT3
0x310C9110 DAI0_DAT4
0x310C9114 DAI0_DAT5
0x310C9118 DAI0_DAT6
0x310C9140 DAI0_FS0
0x310C9144 DAI0_FS1
0x310C9148 DAI0_FS2
0x310C9150 DAI0_FS4
0x310C9180 DAI0_PIN0
0x310C9184 DAI0_PIN1
0x310C9188 DAI0_PIN2
0x310C918C DAI0_PIN3
0x310C9190 DAI0_PIN4
0x310C91C0 DAI0_MISC0
0x310C91C4 DAI0_MISC1
0x310C91E0 DAI0_PBEN0
ADSP-SC58x/ADSP-2158x SHARC+ Processor Hardware Reference
Description
CSPFT1 Component ID2 Register
CSPFT1 Component ID3 Register
Description
DAI0 Clock Routing Control Register 0
DAI0 Clock Routing Control Register 1
DAI0 Clock Routing Control Register 2
DAI0 Clock Routing Control Register 3
DAI0 Clock Routing Control Register 4
DAI0 Clock Routing Control Register 5
DAI0 Serial Data Routing Control Register 0
DAI0 Serial Data Routing Control Register 1
DAI0 Serial Data Routing Control Register 2
DAI0 Serial Data Routing Control Register 3
DAI0 Serial Data Routing Control Register 4
DAI0 Serial Data Routing Control Register 5
DAI0 Serial Data Routing Control Register 6
DAI0 Frame Sync Routing Control Register 0
DAI0 Frame Sync Routing Control Register 1
DAI0 Frame Sync Routing Control Register 2
DAI0 Frame Sync Routing Control Register 4
DAI0 Pin Buffer Assignment Register 0
DAI0 Pin Buffer Assignment Register 1
DAI0 Pin Buffer Assignment Register 2
DAI0 Pin Buffer Assignment Register 3
DAI0 Pin Buffer Assignment Register 4
DAI0 Miscellaneous Control Register 0
DAI0 Miscellaneous Control Register 1
DAI0 Pin Buffer Enable Register 0
ADSP-SC58x Register List
Reset Value
0x00000005
0x000000B1
Reset Value
0x252630C2
0x3DEF7BDE
0x00007BDE
0x3C000000
0x3DEF03DE
0x000003DE
0x08144040
0x0F38B289
0x00000450
0x00000000
0x00000000
0x00000000
0x00FBEFBE
0x2736B4E3
0x3DEF7BDE
0x00007BDE
0x000003DE
0x04C80A94
0x04E84B96
0x03668C98
0x03A714A3
0x05694F9E
0x3DEF7BDE
0x3DEF7BDE
0x0E2482CA
A–43
