Table A-72: ADSP-SC58x EMAC0 MMR Register Addresses (Continued)
Memory Map- Register Name
ped Address
0x3100C008 EMAC0_HASHTBL_HI
0x3100C00C EMAC0_HASHTBL_LO
0x3100C010 EMAC0_SMI_ADDR
0x3100C014 EMAC0_SMI_DATA
0x3100C018 EMAC0_FLOWCTL
0x3100C01C EMAC0_VLANTAG
0x3100C024 EMAC0_DBG
0x3100C030 EMAC0_LPI_CTLSTAT
0x3100C034 EMAC0_LPI_TMRSCTL
0x3100C038 EMAC0_ISTAT
0x3100C03C EMAC0_IMSK
0x3100C040 EMAC0_ADDR0_HI
0x3100C044 EMAC0_ADDR0_LO
0x3100C048 EMAC0_ADDR1_HI
0x3100C04C EMAC0_ADDR1_LO
0x3100C0D8 EMAC0_GIGE_CTLSTAT
0x3100C0DC EMAC0_WDOG_TIMOUT EMAC0 Watchdog Timeout Register
0x3100C100 EMAC0_MMC_CTL
0x3100C104 EMAC0_MMC_RXINT
0x3100C108 EMAC0_MMC_TXINT
0x3100C10C EMAC0_MMC_RXIMSK
0x3100C110 EMAC0_MMC_TXIMSK
0x3100C114 EMAC0_TXOCTCNT_GB
0x3100C118 EMAC0_TXFRMCNT_GB
0x3100C11C EMAC0_TXBCASTFRM_G
0x3100C120 EMAC0_TXMCASTFRM_G EMAC0 Tx Multicast Frames (Good) Register
0x3100C124 EMAC0_TX64_GB
0x3100C128 EMAC0_TX65TO127_GB
0x3100C12C EMAC0_TX128TO255_GB
ADSP-SC58x/ADSP-2158x SHARC+ Processor Hardware Reference
Description
EMAC0 Hash Table High Register
EMAC0 Hash Table Low Register
EMAC0 SMI Address Register
EMAC0 SMI Data Register
EMAC0 FLow Control Register
EMAC0 VLAN Tag Register
EMAC0 Debug Register
EMAC0 Low Power Idle Control and Status Register
EMAC0 Low Power Idle Timeout Register
EMAC0 Interrupt Status Register
EMAC0 Interrupt Mask Register
EMAC0 MAC Address 0 High Register
EMAC0 MAC Address 0 Low Register
EMAC0 MAC Address 1 High Register
EMAC0 MAC Address 1 Low Register
EMAC0 RGMII Control and Status Register
EMAC0 MMC Control Register
EMAC0 MMC Rx Interrupt Register
EMAC0 MMC Tx Interrupt Register
EMAC0 MMC Rx Interrupt Mask Register
EMAC0 MMC TX Interrupt Mask Register
EMAC0 Tx OCT Count (Good/Bad) Register
EMAC0 Tx Frame Count (Good/Bad) Register
EMAC0 Tx Broadcast Frames (Good) Register
EMAC0 Tx 64-Byte Frames (Good/Bad) Register
EMAC0 Tx 65- to 127-Byte Frames (Good/Bad) Register
EMAC0 Tx 128- to 255-Byte Frames (Good/Bad) Regis-
ter
ADSP-SC58x Register List
Reset Value
0x00000000
0x00000000
0x00000000
0x00000000
0x00000000
0x00000000
0x00000000
0x00000000
0x00000000
0x00000000
0x00000000
0x8000FFFF
0xFFFFFFFF
0x00000000
0x00000000
0x00000000
0x00000000
0x00000000
0x00000000
0x00000000
0x00000000
0x00000000
0x00000000
0x00000000
0x00000000
0x00000000
0x00000000
0x00000000
0x00000000
