ADSP-SC58x PKA Register Descriptions
Check PKA_RAM_BASE+0x0B8+0x10== 0x0E81D268
Check PKA_RAM_BASE+0x0B8+0x14== 0x759B9F39
// Y-coord of result point is value
0xECA14640_F92EFF07_CAF2BD55_3FBE28EF_D043F28E_1CC3D238
// written as 2nd part of vector D at PKA RAM Byte offset 0x0D8:
Check PKA_RAM_BASE+0x0D8+0x00== 0x1CC3D238
Check PKA_RAM_BASE+0x0D8+0x04== 0xD043F28E
Check PKA_RAM_BASE+0x0D8+0x08== 0x3FBE28EF
Check PKA_RAM_BASE+0x0D8+0x0C== 0xCAF2BD55
Check PKA_RAM_BASE+0x0D8+0x10== 0xF92EFF07
Check PKA_RAM_BASE+0x0D8+0x14== 0xECA14640
ADSP-SC58x PKA Register Descriptions
Public Key Accelerator (PKA) contains the following registers.
Table 45-23: ADSP-SC58x PKA Register List
Name
PKA_ALEN
PKA_APTR
PKA_BLEN
PKA_BPTR
PKA_COMPARE
PKA_CPTR
PKA_DIVMSW
PKA_DPTR
PKA_FUNC
PKA_RAM
PKA_RESULTMSW
PKA_SHIFT
45–20
Description
PKA Vector_A Length
PKA Vector_A Address
PKA Vector_B Length
PKA Vector_B Address
PKA Compare Result
PKA Vector_C Address
PKA Most-Significant-Word of Divide Remainder
PKA Vector_D Address
PKA Function
Start of PKA RAM space
PKA Most-Significant-Word of Result Vector
PKA Bit Shift Value
