ADSP-SC58x Register List
Table A-54: ADSP-SC58x DMA38 MMR Register Addresses (Continued)
Memory Map- Register Name
ped Address
0x31026234 DMA38_XCNT_CUR
0x31026238 DMA38_YCNT_CUR
Table A-55: ADSP-SC58x DMA39 MMR Register Addresses
Memory Map- Register Name
ped Address
0x3109A000 DMA39_DSCPTR_NXT
0x3109A004 DMA39_ADDRSTART
0x3109A008 DMA39_CFG
0x3109A00C DMA39_XCNT
0x3109A010 DMA39_XMOD
0x3109A014 DMA39_YCNT
0x3109A018 DMA39_YMOD
0x3109A024 DMA39_DSCPTR_CUR
0x3109A028 DMA39_DSCPTR_PRV
0x3109A02C DMA39_ADDR_CUR
0x3109A030 DMA39_STAT
0x3109A034 DMA39_XCNT_CUR
0x3109A038 DMA39_YCNT_CUR
0x3109A040 DMA39_BWLCNT
0x3109A044 DMA39_BWLCNT_CUR
0x3109A048 DMA39_BWMCNT
0x3109A04C DMA39_BWMCNT_CUR
Table A-56: ADSP-SC58x DMA4 MMR Register Addresses
Memory Map- Register Name
ped Address
0x31022200 DMA4_DSCPTR_NXT
0x31022204 DMA4_ADDRSTART
A–66
Description
DMA38 Current Count (1D) or Intra-row XCNT (2D)
Register
DMA38 Current Row Count (2D only) Register
Description
DMA39 Pointer to Next Initial Descriptor Register
DMA39 Start Address of Current Buffer Register
DMA39 Configuration Register
DMA39 Inner Loop Count Start Value Register
DMA39 Inner Loop Address Increment Register
DMA39 Outer Loop Count Start Value (2D only) Regis-
ter
DMA39 Outer Loop Address Increment (2D only) Regis-
ter
DMA39 Current Descriptor Pointer Register
DMA39 Previous Initial Descriptor Pointer Register
DMA39 Current Address Register
DMA39 Status Register
DMA39 Current Count (1D) or Intra-row XCNT (2D)
Register
DMA39 Current Row Count (2D only) Register
DMA39 Bandwidth Limit Count Register
DMA39 Bandwidth Limit Count Current Register
DMA39 Bandwidth Monitor Count Register
DMA39 Bandwidth Monitor Count Current Register
Description
DMA4 Pointer to Next Initial Descriptor Register
DMA4 Start Address of Current Buffer Register
ADSP-SC58x/ADSP-2158x SHARC+ Processor Hardware Reference
Reset Value
0x00000000
0x00000000
Reset Value
0x00000000
0x00000000
0x00000220
0x00000000
0x00000000
0x00000000
0x00000000
0x00000000
0x00000000
0x00000000
0x00006000
0x00000000
0x00000000
0x00000000
0x00000000
0x00000000
0x00000000
Reset Value
0x00000000
0x00000000
