ADSP-SC58x IIR Register Descriptions
IIR Output Data Buffer Length Register
The register provides the output data buffer length.
IIR_OUTLEN
Figure 52-27: IIR_OUTLEN Register Diagram
Table 52-28: IIR_OUTLEN Register Fields
Bit No.
(Access)
15:0 VALUE
(R/W)
52–38
15 14 13
0 0 0
VALUE (R/W)
16-bit Output Data Buffer Length
31 30 29
0 0 0
Bit Name
16-bit Output Data Buffer Length.
The IIR_OUTLEN.VALUE bit field provides the output data buffer length.
