ADSP-SC58x IIR Register Descriptions
Coefficient Buffer Length Register
The register provides the coefficient buffer length.
IIR_COEFLEN
Figure 52-9: IIR_COEFLEN Register Diagram
Table 52-10: IIR_COEFLEN Register Fields
Bit No.
(Access)
15:0 VALUE
(R/W)
52–18
15 14 13
0 0 0
VALUE (R/W)
Coefficient Length
31 30 29
0 0 0
Bit Name
Coefficient Length.
The IIR_COEFLEN.VALUE bit field provides the coefficient buffer length.
