ADSP-SC58x Register List
Table A-69: ADSP-SC58x DMC0 MMR Register Addresses
Memory Map- Register Name
ped Address
0x31071000 DMC0_PHY_CTL0
0x31071004 DMC0_PHY_CTL1
0x31071008 DMC0_PHY_CTL2
0x3107100C DMC0_PHY_CTL3
0x31071010 DMC0_PHY_CTL4
0x31071034 DMC0_CAL_PADCTL0
0x3107103C DMC0_CAL_PADCTL2
Table A-70: ADSP-SC58x DMC1 MMR Register Addresses
Memory Map- Register Name
ped Address
0x31074000 DMC1_PHY_CTL0
0x31074004 DMC1_PHY_CTL1
0x31074008 DMC1_PHY_CTL2
0x3107400C DMC1_PHY_CTL3
0x31074010 DMC1_PHY_CTL4
0x31074034 DMC1_CAL_PADCTL0
0x3107403C DMC1_CAL_PADCTL2
Table A-71: ADSP-SC58x DPM0 MMR Register Addresses
Memory Map- Register Name
ped Address
0x31090000 DPM0_CTL
0x31090004 DPM0_STAT
0x31090070 DPM0_PER_DIS0
0x31090074 DPM0_PER_DIS1
0x31090084 DPM0_REVID
Table A-72: ADSP-SC58x EMAC0 MMR Register Addresses
Memory Map- Register Name
ped Address
0x3100C000 EMAC0_MACCFG
0x3100C004 EMAC0_MACFRMFILT
A–76
Description
DMC0 PHY Control 0 Register
DMC0 PHY Control 1 Register
DMC0 PHY Control 2 Register
DMC0 PHY Control 3 Register
DMC0 PHY Control 4 Register
DMC0 Calibration PAD Control 0 Register
DMC0 Calibration PAD Control 2 Register
Description
DMC1 PHY Control 0 Register
DMC1 PHY Control 1 Register
DMC1 PHY Control 2 Register
DMC1 PHY Control 3 Register
DMC1 PHY Control 4 Register
DMC1 Calibration PAD Control 0 Register
DMC1 Calibration PAD Control 2 Register
Description
DPM0 Control Register
DPM0 Status Register
DPM0 Peripherals Disable Register 0
DPM0 Peripherals Disable Register 1
DPM0 Revision ID
Description
EMAC0 MAC Configuration Register
EMAC0 MAC Rx Frame Filter Register
ADSP-SC58x/ADSP-2158x SHARC+ Processor Hardware Reference
Reset Value
0x00000000
0x00000000
0x00000000
0x00000000
0x00000000
0xE0000000
0x00000000
Reset Value
0x00000000
0x00000000
0x00000000
0x00000000
0x00000000
0xE0000000
0x00000000
Reset Value
0x00000000
0x00000001
0x00000000
0x00000000
0x00000020
Reset Value
0x00008000
0x00000000
