Analog Devices ADSP-SC58 Series Hardware Reference Manual page 3759

ADSP-SC58x Register List
Table A-72: ADSP-SC58x EMAC0 MMR Register Addresses (Continued)
Memory Map- Register Name
ped Address
0x3100C220 EMAC0_RXIPV4_UDSBL_F
RM
0x3100C224 EMAC0_RXIPV6_GD_FRM EMAC0 Rx IPv6 Datagrams Good Frames Register
0x3100C228 EMAC0_RXIPV6_HDR_ER
R_FRM
0x3100C22C EMAC0_RXIPV6_NO-
PAY_FRM
0x3100C230 EMAC0_RXUDP_GD_FRM EMAC0 Rx UDP Good Frames Register
0x3100C234 EMAC0_RXUDP_ERR_FR
M
0x3100C238 EMAC0_RXTCP_GD_FRM EMAC0 Rx TCP Good Frames Register
0x3100C23C EMAC0_RXTCP_ERR_FRM EMAC0 Rx TCP Error Frames Register
0x3100C240 EMAC0_RXICMP_GD_FR
M
0x3100C244 EMAC0_RXICMP_ERR_FR
M
0x3100C250 EMAC0_RXIPV4_GD_OCT EMAC0 Rx IPv4 Datagrams Good Octets Register
0x3100C254 EMAC0_RXIPV4_HDR_ER
R_OCT
0x3100C258 EMAC0_RXIPV4_NO-
PAY_OCT
0x3100C25C EMAC0_RXIPV4_FRAG_O
CT
0x3100C260 EMAC0_RXIPV4_UDSBL_
OCT
0x3100C264 EMAC0_RXIPV6_GD_OCT EMAC0 Rx IPv6 Good Octets Register
0x3100C268 EMAC0_RXIPV6_HDR_ER
R_OCT
0x3100C26C EMAC0_RXIPV6_NO-
PAY_OCT
0x3100C270 EMAC0_RXUDP_GD_OCT EMAC0 Rx UDP Good Octets Register
0x3100C274 EMAC0_RXUDP_ERR_OC
T
0x3100C278 EMAC0_RXTCP_GD_OCT EMAC0 Rx TCP Good Octets Register
A–80
Description
EMAC0 Rx IPv4 UDP Disabled Frames Register
EMAC0 Rx IPv6 Datagrams Header Error Frames Regis-
ter
EMAC0 Rx IPv6 Datagrams No Payload Frames Register
EMAC0 Rx UDP Error Frames Register
EMAC0 Rx ICMP Good Frames Register
EMAC0 Rx ICMP Error Frames Register
EMAC0 Rx IPv4 Datagrams Header Errors Register
EMAC0 Rx IPv4 Datagrams No Payload Octets Register
EMAC0 Rx IPv4 Datagrams Fragmented Octets Register
EMAC0 Rx IPv4 UDP Disabled Octets Register
EMAC0 Rx IPv6 Header Errors Register
EMAC0 Rx IPv6 No Payload Octets Register
EMAC0 Rx UDP Error Octets Register
ADSP-SC58x/ADSP-2158x SHARC+ Processor Hardware Reference
Reset Value
0x00000000
0x00000000
0x00000000
0x00000000
0x00000000
0x00000000
0x00000000
0x00000000
0x00000000
0x00000000
0x00000000
0x00000000
0x00000000
0x00000000
0x00000000
0x00000000
0x00000000
0x00000000
0x00000000
0x00000000
0x00000000
