Table A-65: ADSP-SC58x DMA8 MMR Register Addresses (Continued)
Memory Map-
Register Name
ped Address
0x31028040
DMA8_BWLCNT
0x31028044
DMA8_BWLCNT_CUR
0x31028048
DMA8_BWMCNT
0x3102804C
DMA8_BWMCNT_CUR
Table A-66: ADSP-SC58x DMA9 MMR Register Addresses
Memory Map-
Register Name
ped Address
0x31028080
DMA9_DSCPTR_NXT
0x31028084
DMA9_ADDRSTART
0x31028088
DMA9_CFG
0x3102808C
DMA9_XCNT
0x31028090
DMA9_XMOD
0x31028094
DMA9_YCNT
0x31028098
DMA9_YMOD
0x310280A4
DMA9_DSCPTR_CUR
0x310280A8
DMA9_DSCPTR_PRV
0x310280AC
DMA9_ADDR_CUR
0x310280B0
DMA9_STAT
0x310280B4
DMA9_XCNT_CUR
0x310280B8
DMA9_YCNT_CUR
0x310280C0
DMA9_BWLCNT
0x310280C4
DMA9_BWLCNT_CUR
0x310280C8
DMA9_BWMCNT
0x310280CC
DMA9_BWMCNT_CUR
Table A-67: ADSP-SC58x DMC0 MMR Register Addresses
Memory Map-
Register Name
ped Address
0x31070004
DMC0_CTL
0x31070008
DMC0_STAT
ADSP-SC58x/ADSP-2158x SHARC+ Processor Hardware Reference
Description
DMA8 Bandwidth Limit Count Register
DMA8 Bandwidth Limit Count Current Register
DMA8 Bandwidth Monitor Count Register
DMA8 Bandwidth Monitor Count Current Register
Description
DMA9 Pointer to Next Initial Descriptor Register
DMA9 Start Address of Current Buffer Register
DMA9 Configuration Register
DMA9 Inner Loop Count Start Value Register
DMA9 Inner Loop Address Increment Register
DMA9 Outer Loop Count Start Value (2D only) Register 0x00000000
DMA9 Outer Loop Address Increment (2D only) Register 0x00000000
DMA9 Current Descriptor Pointer Register
DMA9 Previous Initial Descriptor Pointer Register
DMA9 Current Address Register
DMA9 Status Register
DMA9 Current Count (1D) or Intra-row XCNT (2D)
Register
DMA9 Current Row Count (2D only) Register
DMA9 Bandwidth Limit Count Register
DMA9 Bandwidth Limit Count Current Register
DMA9 Bandwidth Monitor Count Register
DMA9 Bandwidth Monitor Count Current Register
Description
DMC0 Control Register
DMC0 Status Register
ADSP-SC58x Register List
Reset Value
0x00000000
0x00000000
0x00000000
0x00000000
Reset Value
0x00000000
0x00000000
0x00000000
0x00000000
0x00000000
0x00000000
0x00000000
0x00000000
0x00006000
0x00000000
0x00000000
0x00000000
0x00000000
0x00000000
0x00000000
Reset Value
0x00000000
0x00000001
A–73
