ADSP-SC58x Register List
Table A-3: ADSP-SC58x ARMETM0 MMR Register Addresses (Continued)
Memory Map- Register Name
ped Address
0x3112C054 ARMETM0_ACVR6
0x3112C058 ARMETM0_ACVR7
0x3112C05C ARMETM0_ACVR8
0x3112C080 ARMETM0_ACTR1
0x3112C084 ARMETM0_ACTR2
0x3112C088 ARMETM0_ACTR3
0x3112C08C ARMETM0_ACTR4
0x3112C090 ARMETM0_ACTR5
0x3112C094 ARMETM0_ACTR6
0x3112C098 ARMETM0_ACTR7
0x3112C09C ARMETM0_ACTR8
0x3112C0C0 ARMETM0_DCVR1
0x3112C0C8 ARMETM0_DCVR3
0x3112C100 ARMETM0_DCMR1
0x3112C108 ARMETM0_DCMR3
0x3112C140 ARMETM0_CNTRLDVR1
0x3112C144 ARMETM0_CNTRLDVR2
0x3112C150 ARMETM0_CNTENR1
0x3112C154 ARMETM0_CNTENR2
0x3112C160 ARMETM0_CNTRLDEVR1 ARMETM0 Counter Reload Event Register 1
0x3112C164 ARMETM0_CNTRLDEVR2 ARMETM0 Counter Reload Event Register 2
0x3112C170 ARMETM0_CNTVR1
0x3112C174 ARMETM0_CNTVR2
0x3112C180 ARMETM0_SQ12EVR
0x3112C184 ARMETM0_SQ21EVR
0x3112C188 ARMETM0_SQ23EVR
0x3112C18C ARMETM0_SQ31EVR
0x3112C190 ARMETM0_SQ32EVR
0x3112C194 ARMETM0_SQ13EVR
0x3112C19C ARMETM0_SQR
0x3112C1A0 ARMETM0_EXTOUTEVR1 ARMETM0 External Output Event Register 1
