ADSP-SC58x Register List
Table A-18: ADSP-SC58x CSPFT1 MMR Register Addresses (Continued)
Memory Map- Register Name
ped Address
0x3110708C CSPFT1_ACTR[n]
0x31107140 CSPFT1_CNTRLDVR[n]
0x31107144 CSPFT1_CNTRLDVR[n]
0x31107150 CSPFT1_CNTENR[n]
0x31107154 CSPFT1_CNTENR[n]
0x31107160 CSPFT1_CNTRLDEVR[n]
0x31107164 CSPFT1_CNTRLDEVR[n]
0x31107170 CSPFT1_CNTVR[n]
0x31107174 CSPFT1_CNTVR[n]
0x311071A0 CSPFT1_EXTOUTEVR[n]
0x311071A4 CSPFT1_EXTOUTEVR[n]
0x311071A8 CSPFT1_EXTOUTEVR[n]
0x311071AC CSPFT1_EXTOUTEVR[n]
0x311071B0 CSPFT1_CIDCVR[n]
0x311071BC CSPFT1_CIDCMR
0x311071E0 CSPFT1_SYNCFR
0x311071E8 CSPFT1_CCER
0x31107200 CSPFT1_TRACEIDR
0x31107FA0 CSPFT1_CLAIMSET
0x31107FA4 CSPFT1_CLAIMCLR
0x31107FB0 CSPFT1_LAR
0x31107FB4 CSPFT1_LSR
0x31107FB8 CSPFT1_AUTHSTATUS
0x31107FCC CSPFT1_DEVTYPE
0x31107FD0 CSPFT1_PID4
0x31107FE0 CSPFT1_PID0
0x31107FE4 CSPFT1_PID1
0x31107FE8 CSPFT1_PID2
0x31107FEC CSPFT1_PID3
0x31107FF0 CSPFT1_CID0
0x31107FF4 CSPFT1_CID1
A–42
Description
CSPFT1 Address Comparator Access Type Register
CSPFT1 Counter Reload Value Register
CSPFT1 Counter Reload Value Register
CSPFT1 Counter Enable Event Register
CSPFT1 Counter Enable Event Register
CSPFT1 Counter Reload Event Register
CSPFT1 Counter Reload Event Register
CSPFT1 Counter Value Register
CSPFT1 Counter Value Register
CSPFT1 External Output Event Register
CSPFT1 External Output Event Register
CSPFT1 External Output Event Register
CSPFT1 External Output Event Register
CSPFT1 Context ID Comparator Value
CSPFT1 Context ID Comparator Mask Register
CSPFT1 Synchronization Frequency Register
CSPFT1 Configuration Code Extension Register
CSPFT1 CoreSight Trace ID Register
CSPFT1 Claim Tag Set Register
CSPFT1 Claim Tag Clear Register
CSPFT1 Lock Access Register
CSPFT1 Lock Status Register
CSPFT1 Authentication Status Register
CSPFT1 Device Type Identifier Register
CSPFT1 Peripheral ID4 Register
CSPFT1 Peripheral ID0 Register
CSPFT1 Peripheral ID1 Register
CSPFT1 Peripheral ID2 Register
CSPFT1 Peripheral ID3 Register
CSPFT1 Component ID0 Register
CSPFT1 Component ID1 Register
ADSP-SC58x/ADSP-2158x SHARC+ Processor Hardware Reference
Reset Value
0x00000000
0x00000000
0x00000000
0x000077EF
0x000077EF
0x000077EF
0x000077EF
0x00000000
0x00000000
0x000077EF
0x000077EF
0x000077EF
0x000077EF
0x00000000
0x00000000
0x00000000
0x00800000
0x00000000
0x0000000F
0x00000000
0x00000000
0x00000003
0x00000080
0x00000023
0x00000000
0x00000000
0x00000050
0x0000000E
0x00000000
0x0000000D
0x00000090
