ADSP-SC58x Register List
Table A-9: ADSP-SC58x CAN1 MMR Register Addresses (Continued)
Memory Map- Register Name
ped Address
0x31000C40 CAN1_MB[nn]_DATA0
0x31000C44 CAN1_MB[nn]_DATA1
0x31000C48 CAN1_MB[nn]_DATA2
0x31000C4C CAN1_MB[nn]_DATA3
0x31000C50 CAN1_MB[nn]_LENGTH
0x31000C54 CAN1_MB[nn]_TIME-
STAMP
0x31000C58 CAN1_MB[nn]_ID0
0x31000C5C CAN1_MB[nn]_ID1
0x31000C60 CAN1_MB[nn]_DATA0
0x31000C64 CAN1_MB[nn]_DATA1
0x31000C68 CAN1_MB[nn]_DATA2
0x31000C6C CAN1_MB[nn]_DATA3
0x31000C70 CAN1_MB[nn]_LENGTH
0x31000C74 CAN1_MB[nn]_TIME-
STAMP
0x31000C78 CAN1_MB[nn]_ID0
0x31000C7C CAN1_MB[nn]_ID1
0x31000C80 CAN1_MB[nn]_DATA0
0x31000C84 CAN1_MB[nn]_DATA1
0x31000C88 CAN1_MB[nn]_DATA2
0x31000C8C CAN1_MB[nn]_DATA3
0x31000C90 CAN1_MB[nn]_LENGTH
0x31000C94 CAN1_MB[nn]_TIME-
STAMP
0x31000C98 CAN1_MB[nn]_ID0
0x31000C9C CAN1_MB[nn]_ID1
0x31000CA0 CAN1_MB[nn]_DATA0
0x31000CA4 CAN1_MB[nn]_DATA1
0x31000CA8 CAN1_MB[nn]_DATA2
0x31000CAC CAN1_MB[nn]_DATA3
0x31000CB0 CAN1_MB[nn]_LENGTH
A–28
Description
CAN1 Mailbox Word 0 Register
CAN1 Mailbox Word 1 Register
CAN1 Mailbox Word 2 Register
CAN1 Mailbox Word 3 Register
CAN1 Mailbox Length Register
CAN1 Mailbox Time Stamp Register
CAN1 Mailbox ID 0 Register
CAN1 Mailbox ID 1 Register
CAN1 Mailbox Word 0 Register
CAN1 Mailbox Word 1 Register
CAN1 Mailbox Word 2 Register
CAN1 Mailbox Word 3 Register
CAN1 Mailbox Length Register
CAN1 Mailbox Time Stamp Register
CAN1 Mailbox ID 0 Register
CAN1 Mailbox ID 1 Register
CAN1 Mailbox Word 0 Register
CAN1 Mailbox Word 1 Register
CAN1 Mailbox Word 2 Register
CAN1 Mailbox Word 3 Register
CAN1 Mailbox Length Register
CAN1 Mailbox Time Stamp Register
CAN1 Mailbox ID 0 Register
CAN1 Mailbox ID 1 Register
CAN1 Mailbox Word 0 Register
CAN1 Mailbox Word 1 Register
CAN1 Mailbox Word 2 Register
CAN1 Mailbox Word 3 Register
CAN1 Mailbox Length Register
ADSP-SC58x/ADSP-2158x SHARC+ Processor Hardware Reference
Reset Value
0x00000000
0x00000000
0x00000000
0x00000000
0x00000000
0x00000000
0x00000000
0x00000000
0x00000000
0x00000000
0x00000000
0x00000000
0x00000000
0x00000000
0x00000000
0x00000000
0x00000000
0x00000000
0x00000000
0x00000000
0x00000000
0x00000000
0x00000000
0x00000000
0x00000000
0x00000000
0x00000000
0x00000000
0x00000000
