ADSP-SC58x Register List
Table A-9: ADSP-SC58x CAN1 MMR Register Addresses (Continued)
Memory Map- Register Name
ped Address
0x31000D24 CAN1_MB[nn]_DATA1
0x31000D28 CAN1_MB[nn]_DATA2
0x31000D2C CAN1_MB[nn]_DATA3
0x31000D30 CAN1_MB[nn]_LENGTH
0x31000D34 CAN1_MB[nn]_TIME-
STAMP
0x31000D38 CAN1_MB[nn]_ID0
0x31000D3C CAN1_MB[nn]_ID1
0x31000D40 CAN1_MB[nn]_DATA0
0x31000D44 CAN1_MB[nn]_DATA1
0x31000D48 CAN1_MB[nn]_DATA2
0x31000D4C CAN1_MB[nn]_DATA3
0x31000D50 CAN1_MB[nn]_LENGTH
0x31000D54 CAN1_MB[nn]_TIME-
STAMP
0x31000D58 CAN1_MB[nn]_ID0
0x31000D5C CAN1_MB[nn]_ID1
0x31000D60 CAN1_MB[nn]_DATA0
0x31000D64 CAN1_MB[nn]_DATA1
0x31000D68 CAN1_MB[nn]_DATA2
0x31000D6C CAN1_MB[nn]_DATA3
0x31000D70 CAN1_MB[nn]_LENGTH
0x31000D74 CAN1_MB[nn]_TIME-
STAMP
0x31000D78 CAN1_MB[nn]_ID0
0x31000D7C CAN1_MB[nn]_ID1
0x31000D80 CAN1_MB[nn]_DATA0
0x31000D84 CAN1_MB[nn]_DATA1
0x31000D88 CAN1_MB[nn]_DATA2
0x31000D8C CAN1_MB[nn]_DATA3
0x31000D90 CAN1_MB[nn]_LENGTH
A–30
Description
CAN1 Mailbox Word 1 Register
CAN1 Mailbox Word 2 Register
CAN1 Mailbox Word 3 Register
CAN1 Mailbox Length Register
CAN1 Mailbox Time Stamp Register
CAN1 Mailbox ID 0 Register
CAN1 Mailbox ID 1 Register
CAN1 Mailbox Word 0 Register
CAN1 Mailbox Word 1 Register
CAN1 Mailbox Word 2 Register
CAN1 Mailbox Word 3 Register
CAN1 Mailbox Length Register
CAN1 Mailbox Time Stamp Register
CAN1 Mailbox ID 0 Register
CAN1 Mailbox ID 1 Register
CAN1 Mailbox Word 0 Register
CAN1 Mailbox Word 1 Register
CAN1 Mailbox Word 2 Register
CAN1 Mailbox Word 3 Register
CAN1 Mailbox Length Register
CAN1 Mailbox Time Stamp Register
CAN1 Mailbox ID 0 Register
CAN1 Mailbox ID 1 Register
CAN1 Mailbox Word 0 Register
CAN1 Mailbox Word 1 Register
CAN1 Mailbox Word 2 Register
CAN1 Mailbox Word 3 Register
CAN1 Mailbox Length Register
ADSP-SC58x/ADSP-2158x SHARC+ Processor Hardware Reference
Reset Value
0x00000000
0x00000000
0x00000000
0x00000000
0x00000000
0x00000000
0x00000000
0x00000000
0x00000000
0x00000000
0x00000000
0x00000000
0x00000000
0x00000000
0x00000000
0x00000000
0x00000000
0x00000000
0x00000000
0x00000000
0x00000000
0x00000000
0x00000000
0x00000000
0x00000000
0x00000000
0x00000000
0x00000000
