ADSP-SC58x HAE Register Descriptions
V (Voltage) Sample Register
The register provides voltage (V) input samples for HAE calculations.
HAE_VSAMPLE
VALUE[23:16] (R/W)
Voltage Input Sample
Figure 49-21: HAE_VSAMPLE Register Diagram
Table 49-21: HAE_VSAMPLE Register Fields
Bit No.
(Access)
23:0 VALUE
(R/W)
49–32
15
0
VALUE[15:0] (R/W)
Voltage Input Sample
31
0
Bit Name
Voltage Input Sample.
The HAE_VSAMPLE.VALUE bits hold the voltage sample if provided by the MCU.
The sample can be timed with the HAE_STAT.RXIRQ bit.
