HELP AND ERROR MESSAGE SHORT-FORM TABLES

1.8 Calibration errors (7xx)

Error
Explanation
code
E701 Missing calibration
E702
E703
E704
E705
E706
Technical Manual
Tube head filament definition not done
Tube head kV-calibration not done
Panoramic AEC not calibrated
Cephalometric AEC not calibrated
Problem during the preheat calibration.
Problem with the preheat calibration.
Chapter C - ERROR MESSAGES
Comments
Perform the preheat calibration
again.
Perform the preheat calibration
again.
Calibrate the AEC-PAN.
Calibrate the AEC-CEPH.
The current in the tube head is
not high enough. Perform the
preheat calibration again.
The current in the tube head is
not raising on the voltage area.
Perform the preheat calibration
again. Check the functionality of
the tube head.
ProMax X-ray unit with Dimax3 C-13
