USER'S STATEMENT FOR PROMAX X-RAY

5 USER'S STATEMENT FOR PROMAX X-RAY
Radiation leakage technique factors
Filtration
Maximum attenuation equivalent of the front panel of the
panoramic cassette holder
Rated line voltage
Maximum line current
Technique factors that constitute the maximum line current
condition
Generator rating and duty cycle
Maximum deviation of peak tube potential from indicated value
Maximum deviation of tube current from indicated value
Maximum deviation of exposure time from indicated value
Technical Manual
The maximum rated peak tube potential is 84 kV and the maximum rated continuous tube
current is 3 mA for the maximum rated peak tube voltage.
The Radiation port contains additional filtration of at least 2 mm aluminium.
Total filtration min. 2.5 mmAl.
When the X-ray beam is attenuated with the 2.5 mmAl the resulting dose is 0.5 - 0.6 times the
original.
0.5 mmAl
100 - 240 V~ ±10%
Maximum 15 Amperes at 100 V~, 8A at 230 V~
84 kV / 16 mA
1.5 kW, duty cycle approximately 1:10. The wait period is calculated using the following for-
mula:
t = f(HS - HS ) - f(HS
w MAX 1
where HS = maximum tube anode heat storage capacity (28 kJ)
MAX
HS = current tube anode heat storage
0
HS = heat storage caused by next intended exposure (kV x mA x s)
1
f = tube anode cooling rate as a function of heat storage (given by tube
manufacturer)
±5%
±10%
±10%
)
0
Chapter A - GENERAL & TECHNICAL DATA
ProMax X-ray unit with Dimax3 A-5
