5.7 Patient support alignment

NOTE
Technical Manual
It is important to perform the Reset system configuration function in case some
device(s) has/have been added or removed from the X-ray unit.
The quick button values (kV/mA) cannot be reset but you have to change the values by
programming.
In the Service settings it is possible to perform a patient support alingment checkup and to do
a fine tuning of the patient support by choosing from the Service settings Patient support
alignment (i580).
The fine tuning is done after the mechanical adjustment of the patient support.
Figure 42
The alignment procedure is explained in section 1.12 "Additional adjustment method of the
patient support alignment" on page E-52.
