DETACHING AND ATTACHING THE SENSOR HEAD
Button of the cephalostat
electrical connector
Technical manual
Turn the locking knob over the fastening mechanism. This will secure the sensor head in posi-
tion.
Figure 101
Push in the button of the cephalostat electrical connector behind the sensor head quick con-
nector mechanism. This will secure the sensor head in position and make the electrical con-
nection between the sensor head and cephalostat.
Figure 102
Chapter H - CEPHALOSTAT
Locking knob
ProMax X-ray unit with Dimax3 H-57
