HELP AND ERROR MESSAGE SHORT-FORM TABLES

1.5 Feedback errors (4xx)

Error
Explanation
code
E401 Tube head offsets
E402
E403
E404
E405
E406
E407
E408
E409
E411 Tube head signals
E412
E413
E414
E415
E416
E417
Technical Manual
KVPOS failure - shorted
KVPOS failure - out of bounds
KVNEG failure - shorted
KVNEG failure - out of bounds
MAPOS failure - shorted
MAPOS failure - out of bounds
MANEG failure - shorted
MANEG failure - out of bounds
FILAMENT failure - out of bounds
kV-feedback imbalance
mA-feedback imbalance
tube head grounding error
temperature measurement error (signal
out of bounds)
tube head electronics supply voltage
error
Tube head not calibrated
Tube head is of non-supported type
(reserved)
Chapter C - ERROR MESSAGES
Comments
Exposure not possible. Check the
cabling between the FBK and the
CAM PCB. Check also the func-
tionality of the FBK PCB.
Exposure not possible. Check the
cabling between the FBK and the
CAM PCB. Check also the func-
tionality of the FBK PCB.
Exposure not possible. Check the
cabling between the FBK and the
CAM PCB. Check also the func-
tionality of the FBK PCB.
Exposure not possible. Check the
cabling between the FBK and the
CAM PCB. Check also the func-
tionality of the FBK PCB.
Exposure not possible. Check the
cabling between the FBK and the
CAM PCB. Check also the func-
tionality of the FBK PCB.
Exposure not possible. Check the
cabling between the FBK and the
CAM PCB. Check also the func-
tionality of the FBK PCB.
Exposure not possible. Check the
functionality of the FBK PCB.
Exposure not possible. Check the
functionality of the FBK PCB.
Exposure not possible. Check the
functionality of the FBK PCB.
Exposure interrupted.
Exposure interrupted.
Exposure not possible.
Exposure not possible. Check the
temperature measurement sen-
sor and the FBK PCB.
Check the FBK PCB and the
cabling between the FBK and the
CAM PCB.
Exposure not possible. Perform
the preheat calibration again.
Check the functionality of the
FBK PCB.
Exposure not possible.
ProMax X-ray unit with Dimax3 C-9
