1
Brown
2
White
10002150
1 POTGND Green
2 POT
3 POT5V
121-10-24
Layer Potentiometer
1
Brown
3
White
1 GND
Brown
2 Voltage White
4
1
J1
J3
J2
5
2
6 3
J5
J6
121-10-10
Brown
Patient Position Control PCB
White
PPC
Stop
Switch
J8
1
Brown
2
Brown
10003366
1 TMOTC
Brown
2 TMOTB
Green
3 TMOTA
White
4 +5V (NC)
5 TREFOUT Brown
6 GND
White
10002147
J4
Chinrest
Sensor
J7
PLANMECA OY
Asentajankatu 6
00810 Helsinki Finland
121-10-03
J12
CPU PCB
1 LAS_MID
2 LAS_LAY
3 LAS_GND
4 TMOTC
5 TMOTB
6 TMOA
7 GND
8 +5V
9 POTGND
10 POT
11 POT5V
12 STOP
13 TREFOUT
14 DOUT
15 DIN
16 CLK
ProMax
20.12.2001
WIRING DIAGRAM
Patient Support
L.Ylen
Rev 1.1 / 01.04.2003 LY
