Chapter E - C-ARM AND IMAGING ARM
Remove the shoulder arm cover. Slide the alignment pin through the hole in the shoulder joint
so that it goes into the positioning holes in the shoulder arm and column. Slide the other align-
ment pin through the hole in the elbow joint so that it goes into the positioning hole in the C-
arm. The positions of the alignment pins are shown on the Fig. 92 below.
Figure 92
E-58 ProMax X-ray unit with Dimax3
Positions of the alignment pins.
OTHER ADJUSTMENTS AND CALIBRATIONS
Shoulder joint pin
Elbow and C-arm
joint pin
