VLT® AutomationDrive EZ FC 321
Programming Guide
View the total reference, the sum of digital, analog, preset, fieldbus, and freeze references, plus catch up and slow down.
Parameter 16-51 Pulse Reference
Table 619: Parameter 16-51 Pulse Reference
16-51 Pulse Reference
Default Value: 0
Conversion Index: -1
View the reference value from programmed digital inputs. The readout can also reflect the impulses from an incremental encoder.
Parameter 16-52 Feedback[Unit]
Table 620: Parameter 16-52 Feedback[Unit]
16-52 Feedback[Unit]
Default Value: 0 ReferenceFeedback-
Unit
Conversion Index: -3
View the feedback unit resulting from the selection of unit and scaling in parameter 3-00 Reference Range, parameter 3-01 Reference/
Feedback Unit, parameter 3-02 Minimum Reference, and parameter 3-03 Maximum Reference.
Parameter 16-53 Digi Pot Reference
Table 621: Parameter 16-53 Digi Pot Reference
16-53 Digi Pot Reference
Default Value: 0
Conversion Index: -2
View the contribution of the digital potentiometer to the actual reference.
Parameter 16-57 Feedback [RPM]
Table 622: Parameter 16-57 Feedback [RPM]
16-57 Feedback [RPM]
Default Value: 0 RPM
Conversion Index: 67
Readout parameter where the actual motor RPM from the feedback source can be read in both closed loop and open loop. The
feedback source is selected in parameter 7-00 Speed PID Feedback Source.

4.16.5 16-6* Inputs and Outputs

Parameter 16-61 Terminal 53 Switch Setting
Table 623: Parameter 16-61 Terminal 53 Switch Setting
16-61 Terminal 53 Switch Setting
Default Value: [0] Current
Conversion Index: -
View the setting of input terminal 53.
310 | Danfoss A/S © 2021.08
Parameter Type: Range, -200 - 200
Data Type: Int16
Parameter Type: Range, -999999.999 ReferenceFeed-
backUnit - 999999.999 ReferenceFeedbackUnit
Data Type: Int32
Parameter Type: Range, -200 - 200
Data Type: Int16
Parameter Type: Range, -30000 - 30000 RPM
Data Type: Int32
Parameter Type: Option
Data Type: Uint8
Parameter Descriptions
Setup: All set-ups
Change during operation: False
Setup: All set-ups
Change during operation:
False
Setup: All set-ups
Change during operation: False
Setup: All set-ups
Change during operation: False
Setup: All set-ups
Change during operation: False
AU373327181955en-000101 / 130R1208
