VLT® AutomationDrive EZ FC 321
Programming Guide
View the control word sent from the drive via the serial communication port in hex code.
Parameter 16-01 Reference [Unit]
Table 578: Parameter 16-01 Reference [Unit]
16-01 Reference [Unit]
Default Value: 0 ReferenceFeedbackU-
nit
Conversion Index: -3
View the present reference value applied on impulse or analog basis in the unit resulting from the configuration selected in parame-
ter 1-00 Configuration Mode (Hz, Nm, or RPM).
Parameter 16-02 Reference %
Table 579: Parameter 16-02 Reference %
16-02 Reference %
Default Value: 0%
Conversion Index: -1
View the total reference. The total reference is the sum of digital, analog, preset, bus, and freeze references plus catch up and slow
down.
Parameter 16-03 Status Word
Table 580: Parameter 16-03 Status Word
16-03 Status Word
Default Value: 0
Conversion Index: 0
View the status word sent from the drive via the serial communication port in hex code.
Parameter 16-05 Main Actual Value [%]
Table 581: Parameter 16-05 Main Actual Value [%]
16-05 Main Actual Value [%]
Default Value: 0%
Conversion Index: -2
View the 2-byte word sent with the status word to the fieldbus master reporting the main actual value.
Parameter 16-09 Customer Readout
Table 582: Parameter 16-09 Customer Readout
16-09 Customer Readout
Default Value: 0 CustomReadoutUnit
Conversion Index: -2
View the value of custom readout from parameter 0-30 Unit for Userdefined Readout to parameter 0-32 Custom Readout Max Value.
302 | Danfoss A/S © 2021.08
Parameter Type: Range, -999999 ReferenceFeedback-
Unit - 999999 ReferenceFeedbackUnit
Data Type: Int32
Parameter Type: Range, -200 - 200%
Data Type: Int16
Parameter Type: Range, 0 - 65535
Data Type: V2
Parameter Type: Range, -100 - 100%
Data Type: N2
Parameter Type: Range, 0 CustomReadoutUnit -
999999.99 CustomReadoutUnit
Data Type: Int32
Parameter Descriptions
Setup: All set-ups
Change during operation: False
Setup: All set-ups
Change during operation: False
Setup: All set-ups
Change during operation: False
Setup: All set-ups
Change during operation: False
Setup: All set-ups
Change during operation: False
