VLT® AutomationDrive EZ FC 321
Programming Guide
Option
Name
[101]
RS Flipflop 7
[102]
Relay 1
[103]
Relay 2
Parameter 13-52 SL Controller Action
Table 468: Parameter 13-52 SL Controller Action
13-52 SL Controller Action
Default Value:Size related
Conversion Index: -
Select the action corresponding to the SLC event. Actions are executed when the corresponding event (defined in parameter 13-51
SL Controller 1 Event) is evaluated as true.
Option
Name
[0]
DISABLED
[1]
No action
[2]
Select set-up 1
[3]
Select set-up 2
[4]
Select set-up 3
[5]
Select set-up 4
[10]
Select preset ref 0
[11]
Select preset ref 1
[12]
Select preset ref 2
[13]
Select preset ref 3
[14]
Select preset ref 4
[15]
Select preset ref 5
[16]
Select preset ref 6
[17]
Select preset ref 7
[18]
Select ramp 1
Danfoss A/S © 2021.08
Description
See parameter group 13-1* Comparators.
Parameter Type: Option, Array [10]
Data Type: Uint8
Description
Changes the active setup (parameter 0-10 Active Set-up) to 1. If the setup is changed, it merges
with other setup commands coming from either the digital inputs or via a fieldbus.
Changes the active setup (parameter 0-10 Active Set-up) to 2. If the setup is changed, it merges
with other set-up commands coming from either the digital inputs or via a fieldbus.
Changes the active setup (parameter 0-10 Active Set-up) to 3. If the setup is changed, it merges
with other setup commands coming from either the digital inputs or via a fieldbus.
Changes the active setup (parameter 0-10 Active Set-up) to 4. If the setup is changed, it merges
with other setup commands coming from either the digital inputs or via a fieldbus.
Selects preset reference 0. If the active preset reference is changed, it merges with other preset
reference commands coming from either the digital inputs or via a fieldbus.
Selects preset reference 1. If the active preset reference is changed, it merges with other preset
reference commands coming from either the digital inputs or via a fieldbus.
Selects preset reference 2. If the active preset reference is changed, it merges with other preset
reference commands coming from either the digital inputs or via a fieldbus.
Selects preset reference 3. If the active preset reference is changed, it merges with other preset
reference commands coming from either the digital inputs or via a fieldbus.
Selects preset reference 4. If the active preset reference is changed, it merges with other preset
reference commands coming from either the digital inputs or via a fieldbus.
Selects preset reference 5. If the active preset reference is changed, it merges with other preset
reference commands coming from either the digital inputs or via a fieldbus.
Selects preset reference 6. If the active preset reference is changed, it merges with other preset
reference commands coming from either the digital inputs or via a fieldbus.
Selects preset reference 7. If the active preset reference is changed, it merges with other preset
reference commands coming from either the digital inputs or via a fieldbus.
Selects ramp 1.
Parameter Descriptions
Setup: 2 set-ups
Change during operation: True
AU373327181955en-000101 / 130R1208 | 259
