VLT® AutomationDrive EZ FC 321
Programming Guide
Option Name
[50] On reference
[60] Comparator 0
[61] Comparator 1
[62] Comparator 2
[63] Comparator 3
[64] Comparator 4
[65] Comparator 5
[70] Logic rule 0
[71] Logic rule 1
[72] Logic rule 2
[73] Logic rule 3
[74] Logic rule 4
[75] Logic rule 5
[79] PE power off
[80] SL digital output A
[81] SL digital output B
[82] SL digital output C
[83] SL digital output D
[84] SL digital output E
[85] SL digital output F
[90] kWh counter pulse
[120] Local ref active
Danfoss A/S © 2021.08
Description
See parameter group 13-1* Comparators. If comparator 0 in SLC is true, the output goes high.
Otherwise, it is low.
See parameter group 13-1* Comparators. If comparator 1 in SLC is true, the output goes high.
Otherwise, it is low.
See parameter group 13-1* Comparators. If comparator 2 in SLC is true, the output goes high.
Otherwise, it is low.
See parameter group 13-1* Comparators. If comparator 3 in SLC is true, the output goes high.
Otherwise, it is low.
See parameter group 13-1* Comparators. If comparator 4 in SLC is true, the output goes high.
Otherwise, it is low.
See parameter group 13-1* Comparators. If comparator 5 in SLC is true, the output goes high.
Otherwise, it is low.
See parameter group 13-4* Logic Rules. If logic rule 0 in SLC is true, the output goes high. Other-
wise, it is low.
See parameter group 13-4* Logic Rules. If logic rule 1 in SLC is true, the output goes high. Other-
wise, it is low.
See parameter group 13-4* Logic Rules. If logic rule 2 in SLC is true, the output goes high. Other-
wise, it is low.
See parameter group 13-4* Logic Rules. If logic rule 3 in SLC is true, the output goes high. Other-
wise, it is low.
See parameter group 13-4* Logic Rules. If logic rule 4 in SLC is true, the output goes high. Other-
wise, it is low.
See parameter group 13-4* Logic Rules. If logic rule 5 in SLC is true, the output goes high. Other-
wise, it is low.
See parameter 13-52 SL Controller Action. Output A is low on smart logic action [32] Set digital
out A low. Output A is high on smart logic action [38].
See parameter 13-52 SL Controller Action. Output B is low on smart logic action [33] Set digital
out B low. Output B is high on smart logic action [39].
See parameter 13-52 SL Controller Action. Output C is low on smart logic action [34] Set digital
out C low. Output C is high on smart logic action [40].
See parameter 13-52 SL Controller 1 Action. Output D is low on smart logic action [35] Set digital
out D low. Output D is high on smart logic action [41].
See parameter 13-52 SL Controller Action. Output E is low on smart logic action [36] Set digital
out E low. Output E is high on smart logic action [42].
See parameter 13-52 SL Controller Action. Output F is low on smart logic action [37] Set digital
out F low. Output F is high on smart logic action [43].
Output is high when parameter 3-13 Reference Site = [2] Local or when parameter 3-13 Reference
Site = [0] Linked to hand auto at the same time as the LCP is in hand-on mode.
