VLT® AutomationDrive EZ FC 321
Programming Guide
# Alarm log data
• Priority real-time clock (if available).
• Priority operating time (if RTC is not available).
2 Alarm code
3 Frequency
4 Speed (RPM)
5 Reference (%)
7 DC-link voltage
9 Motor phase U current
10 Motor phase V current
11 Motor phase W current
12 Motor phase voltage
15 Control word
16 Status word

4.15.4 Clearing the Service Log

The flash memory stores up to 24 records. To save more logs, clear the service log memory.
Save the service log records using the VLT® Motion Control Tool MCT 10 before clearing the service log.
Clear the service log after a commissioning to remove any alarms that occurred during testing.
Procedure
1.
Select option [5] Clear Service Log in parameter 14-22 Operation Mode.
2. Power cycle the drive. Clearing the service log extends the power-up time by approximately 1 s.

4.15.5 Service Log Indication

Parameter 16-42 Service Log Counter shows the number of service logs stored in the memory.
The drive indicates a full service log memory in 1 of the following ways:
•
The LCP shows the message: Clear logs Service log full: 28 [M26].
•
Bit 25 is set high in parameter 16-96 Maintenance Word (0x2000000).
Performing the drive initialization does not clear the service log memory.

4.15.6 Reading the Service Log Information

See the VLT® Motion Control Tool MCT 10 to read the service log information.
Procedure
1. Open the MCT 10 software.
2. Select a drive.
3. Select the Service Log plug-in.
Danfoss A/S © 2021.08
Parameter
Parameter 15-30 Fault Log: Error Code
Parameter 16-13 Frequency
Parameter 16-17 Speed [RPM]
Parameter 16-02 Reference %
Parameter 16-30 DC Link Voltage
Parameter 16-45 Motor Phase U Current
Parameter 16-46 Motor Phase V Current
Parameter 16-47 Motor Phase W Current
Parameter 16-12 Motor Voltage
Parameter 16-00 Control Word
Parameter 16-03 Status Word
Parameter Descriptions
AU373327181955en-000101 / 130R1208 | 291
