Table 336: Bus-controlled Digital Outputs and Relays
Bit Output/Relay
0 Digital output terminal 27
1 Digital output terminal 29
2 Digital output terminal X30/6
3 Digital output terminal X30/7
4 Relay 1 output terminal
5 Relay 2 output terminal
6 Option B relay 1 output terminal
7 Option B relay 2 output terminal
8 Option B relay 3 output terminal
9-15 Reserved for future terminals
16 Option C relay 1 output terminal
17 Option C relay 2 output terminal
18 Option C relay 3 output terminal
19 Option C relay 4 output terminal
20 Option C realy 5 output terminal
21 Option C relay 6 output terminal
22 Option C relay 7 output terminal
23 Option C relay 8 output terminal
21–31 Reserved for future terminals
Parameter 5-93 Pulse Out #27 Bus Control
Table 337: Parameter 5-93 Pulse Out #27 Bus Control
5-93 Pulse Out #27 Bus Control
Default value: 0%
Conversion index: -2
Set the output frequency transferred to output terminal 27 when the terminal is configured as [45] Bus Controlled in parameter 5-60
Terminal 27 Pulse Output Variable.
Parameter 5-94 Pulse Out #27 Timeout Preset
Table 338: Parameter 5-94 Pulse Out #27 Timeout Preset
5-94 Pulse Out #27 Timeout Preset
Default value: 0%
Conversion index: -2
Set the output frequency transferred to output terminal 27 when the terminal is configured as [48] Bus Ctrl Timeout in parameter
5-60 Terminal 27 Pulse Output Variable and a timeout is detected.
