VLT® AutomationDrive EZ FC 321
Programming Guide
Option Name
[97] RS Flipflop 3
[98] RS Flipflop 4
[99] RS Flipflop 5
[100] RS Flipflop 6
[101] RS Flipflop 7
[102] Relay 1
[103] Relay 2

4.13.5 13-5* States

Parameter 13-51 SL Controller Event
Table 467: Parameter 13-51 SL Controller Event
13-51 SL Controller Event
Default Value:Size related
Conversion Index: -
Select the boolean input (true or false) to define the smart logic controller event. See parameter 13-01 Start Event (options [0] False–
[61] Logic rule 5) and parameter 13-02 Stop Event (options [70] SL Time-out 3–[74] SL Time-out 7) for more information.
Option Name
[0] False
[1] True
[2] Running
[3] In range
[4] On reference
[5] Torque limit
[6] Current limit
[7] Out of current range
[8] Below I low
[9] Above I high
[10] Out of speed range
[11] Below speed low
[12] Above speed high
[13] Out of feedb. range
[14] Below feedb. low
[15] Above feedb. high
[16] Thermal warning
256 | Danfoss A/S © 2021.08
Description
See parameter group 13-1* Comparators.
See parameter group 13-1* Comparators.
See parameter group 13-1* Comparators.
See parameter group 13-1* Comparators.
See parameter group 13-1* Comparators.
Parameter Type: Option, Array [20]
Data Type: Uint8
Description
Parameter Descriptions
Setup: 2 set-ups
Change during operation: True
AU373327181955en-000101 / 130R1208
