VLT® AutomationDrive EZ FC 321
Programming Guide
Option Name
[19] Warning
[20] Alarm (trip)
[21] Alarm (trip lock)
[22] Comparator 0
[23] Comparator 1
[24] Comparator 2
[25] Comparator 3
[26] Logic rule 0
[27] Logic rule 1
[28] Logic rule 2
[29] Logic rule 3
[33] Digital input DI18
[34] Digital input DI19
[35] Digital input DI27
[36] Digital input DI29
[37] Digital input DI32
[38] Digital input DI33
[39] Start command
[40] Drive stopped
[41] Reset trip
[42] Auto-reset trip
[43] OK key
[44] Reset key
[45] Left key
[46] Right key
[47] Up key
[48] Down key
[50] Comparator 4
[51] Comparator 5
[60] Logic rule 4
[61] Logic rule 5
[70] SL time-out 3
248 | Danfoss A/S © 2021.08
Description
[OK] is pressed. Only available on the graphical LCP.
[Reset] is pressed. Only available on the graphical LCP.
[◃] is pressed. Only available on the graphical LCP.
[▹] is pressed. Only available on the graphical LCP.
[▵] is pressed. Only available on the graphical LCP.
[▿] is pressed. Only available on the graphical LCP.
Use the result of comparator 4.
Use the result of comparator 5.
Use the result of logic rule 4.
Use the result of logic rule 5.
Parameter Descriptions
