Parameter 8-13 Configurable Status Word STW
Table 418: Parameter 8-13 Configurable Status Word STW
8-13 Configurable Status Word STW
Default value: Size related
Conversion index: –
Select the interpretation of the control and status words corresponding to the installed fieldbus. Only the selections valid for the
fieldbus installed in slot A are visible in the LCP display. For more guidelines in the selection of [1] PROFIdrive profile, refer to the
Installation Guide for the installed fieldbus.
Option
Name
[0]
No function
[1]
Profile default
[2]
Alarm 68 Only
[3]
Trip excl Alarm 68
[10]
T18DI status
[11]
T19DI status
[12]
T27DI status
[13]
T29DI status
[14]
T32DI status
[15]
T33DI status
[16]
T37DI status
[17]
X30/2 DI status
[18]
X30/3 DI status
[19]
X30/4 DI status
[20]
CTW timeout toggle inverse
[21]
Thermal warning
[30]
Brake fault (IGBT)
[40]
Out of ref range
[49]
Derate active
[54]
Running
Danfoss A/S © 2021.08
Name
FC profile
PROFIdrive profile
ODVA
CANopen DSP 402
Parameter type: Option
Data type: Uint8
Description
The input is always low.
Dependent on the profile set in parameter 8-10 Control Profile.
The input goes high whenever Alarm 68 Safe Stop Activated is active and goes low when-
ever Alarm 68 Safe Stop Activated is not activated.
The input goes high whenever T37 has 0 V and goes low whenever T37 has 24 V.
Parameter Descriptions
Description
Setup: All setups
Change during operation: True
AU373327181955en-000101 / 130R1208 | 207
