VLT® AutomationDrive EZ FC 321
Programming Guide
Parameter 16-79 Analog Out X45/3 [mA]
Table 639: Parameter 16-79 Analog Out X45/3 [mA]
16-79 Analog Out X45/3 [mA]
Default Value: 0
Conversion Index: -3
Shows the actual output value at terminal X45/3. The value shown reflects the selection in parameter 6-80 Terminal X45/3 Output.
4.16.6 16-8* Fieldbus & FC Port
Parameter 16-80 Fieldbus CTW 1
Table 640: Parameter 16-80 Fieldbus CTW 1
16-80 Fieldbus CTW 1
Default Value: 0
Conversion Index: 0
View the 2-byte control word (CTW) received from the bus-master. Interpretation of the CTW depends on the fieldbus option instal-
led and the CTW profile selected in parameter 8-10 Control Word Profile. For more information, refer to the relevant fieldbus manual.
Parameter 16-82 Fieldbus REF 1
Table 641: Parameter 16-82 Fieldbus REF 1
16-82 Fieldbus REF 1
Default Value: 0
Conversion Index: 0
View the 2-byte word sent with the control word form the bus-master to set the reference value. For more information, refer to the
relevant fieldbus manual.
Parameter 16-84 Comm. Option STW
Table 642: Parameter 16-84 Comm. Option STW
16-84 Comm. Option STW
Default Value: 0
Conversion Index: 0
Show the status word of the extended fieldbus communication option. For more information, refer to the relevant fieldbus manual.
Parameter 16-85 FC Port CTW 1
Table 643: Parameter 16-85 FC Port CTW 1
16-85 FC Port CTW 1
Default Value: 0
Conversion Index: 0
View the 2-byte control word (CTW) received from the fieldbus master. Interpretation of the control word depends on the fieldbus
option installed and the control word profile selected in parameter 8-10 Control Word Profile.
314 | Danfoss A/S © 2021.08
Parameter Type: Range, 0 - 30
Data Type: Int16
Parameter Type: Range, 0 - 65535
Data Type: V2
Parameter Type: Range, -200 - 200
Data Type: N2
Parameter Type: Range, 0 - 65535
Data Type: V2
Parameter Type: Range, 0 - 65535
Data Type: V2
Parameter Descriptions
Setup: All set-ups
Change during operation: False
Setup: All set-ups
Change during operation: False
Setup: All set-ups
Change during operation: False
Setup: All set-ups
Change during operation: False
Setup: All set-ups
Change during operation: False
AU373327181955en-000101 / 130R1208
