VLT® AutomationDrive EZ FC 321
Programming Guide
Parameter 13-43 Logic Rule Operator 2
Table 465: Parameter 13-43 Logic Rule Operator 2
13-43 Logic Rule Operator 2
Default Value:Size related
Conversion Index: -
nd
Select the 2 logical operator to be used on the boolean input calculated in:
•
Parameter 13-40 Logic Rule Boolean 1.
•
Parameter 13-41 Logic Rule Operator 1.
• Parameter 13-42 Logic Rule Boolean 2.
[13-44] signifies the boolean input of parameter 13-44 Logic Rule Boolean 3. [13-40/13-42] signifies the boolean input calculated in:
• Parameter 13-40 Logic Rule Boolean 1.
•
Parameter 13-41 Logic Rule Operator 1.
•
Parameter 13-42 Logic Rule Boolean 2.
Option
[0]
[1]
[2]
[3]
[4]
[5]
[6]
[7]
[8]
Parameter 13-44 Logic Rule Boolean 3
Table 466: Parameter 13-44 Logic Rule Boolean 3
13-44 Logic Rule Boolean 3
Default Value: Size related
Conversion Index: -
Option Name
[0] False
[1] True
[2] Running
[3] In range
[4] On reference
Danfoss A/S © 2021.08
Parameter Type: Option, Array [10]
Data Type: Uint8
Name
DISABLED
AND
OR
AND NOT
OR NOT
NOT AND
NOT OR
NOT AND NOT
NOT OR NOT
Parameter Type: Option, Array [10]
Data Type: Uint8
Description
rd
Select the 3 boolean (true or false) input for the selected logic rule. See parameter 13-01 Start
Event (options [0] False–[61] Logic rule 5) and parameter 13-02 Stop Event (options [70] SL Time-
out 3–[75] Start command given) for more information.
Parameter Descriptions
Setup: 2 set-ups
Change during operation: True
Description
Setup: 2 set-ups
Change during operation: True
