2.5 Lifting the Drive

LIFTING HEAVY LOAD
The weight of the drive is heavy and failure to follow local safety regulations for lifting heavy weights may cause death, personal
injury, or property damage.
-
Ensure that the lifting equipment is in proper working condition.
-
Check the weight of the drive and verify that the lifting equipment can safely lift the weight.
-
Always lift the drive using a lifting bar inserted into the lifting eyes. Maximum diameter for the lifting bar: 20 mm (0.8 in).
-
The angle from the top of the drive to the lifting cable: 60° or greater.
-
Test lift the unit approximately 610 mm (24 in) to verify the proper center of gravity lift point. Reposition the lifting point if
the unit is not level.
Table 3: Drive Weights and Dimensions
Enclosure size
A2
A3
A5
B1
B2
B3
B4
C1
C2
C3
C4
D1h
D2h
D3h
D4h
Danfoss A/S © 2021.08
N O T I C E
Protection rating
IP20/Chassis
IP20/Chassis
IP66 - Type 4X
IP66 - Type 4X
IP66 - Type 4X
IP20/Chassis
IP20/Chassis
IP66 - Type 4X
IP66 - Type 4X
IP20/Chassis
IP20/Chassis
Type 12
Type 12
IP20/Chassis
IP20/Chassis
Dimensions (HxWxD) [in]
10.6x3.6x8.7
10.6x5.2x8.7
16.6x9.6x7.9
18.9x9.6x10.3
25.6x9.6x10x3
15.8x6.5x9.8
20.5x9.1x9.6
26.8x12.2x12.3
30.4x14.6x13.2
21.7x12.2x13
26x14.6x13
35.5x12.8x14.9
43.6x12.8x14.9
35.8x19.8x14.8
44.2x14.8x14.8
Safety Instructions
Weight [lb]
10.8
14.6
31.5
51
60
26.5
52
99
143
77
110
136.7
275.6
136.7
238.1
