VLT® AutomationDrive EZ FC 321
Programming Guide
Parameter 5-26 Terminal X46/13 Digital Input
Table 307: Parameter 5-26 Terminal X46/13 Digital Input
5-26 Terminal X46/13 Digital Input
Default value: [0] No operation
Conversion index: –
The options for this parameter are the same as those listed for parameter 5-20 Terminal X46/1 Digital Input.

4.6.3 5-3* Digital Outputs

The 2 solid-state digital outputs are common for terminals 27 and 29. Set the I/O function for terminal 27 in parameter 5-01 Terminal
27 Mode, and set the I/O function for terminal 29 in parameter 5-02 Terminal 29 Mode.
These parameters cannot be adjusted while the motor is running.
Table 308: Digital Outputs, Function Descriptions - 1
Option
[0] No operation
[1] Control ready
[2] Drive ready
[3] Drive rdy/rem ctrl
[4] Enable/no warning
[5] Running
[6] Running/no warning
[7] Run inrange/no warn
[8] Run on ref/no warn
[9] Alarm
[10] Alarm or warning
[11] At torque limit
[12] Out of current range
[13] Below current, low
[14] Above current, high
[15] Out of speed range
[16] Below speed, low
[17] Above speed, high
Danfoss A/S © 2021.08
Parameter type: Option
Data type: Uint8
N O T I C E
Function
Default for all digital outputs and relay outputs.
The control card is ready.
The drive is ready for operation and applies a supply signal on the control card.
The drive is ready for operation and is in auto-on mode.
Ready for operation. No start or stop command has been given (start/disable). No warnings are
active.
The motor runs, and shaft torque is present.
The output speed is higher than the speed set in parameter 1-81 Min Speed for Function at Stop
[RPM]. The motor runs and there are no warnings.
The motor runs within the programmed current and speed ranges set in parameter 4-50 Warning
Current Low to parameter 4-53 Warning Speed High. There are no warnings.
The motor runs at reference speed. There are no warnings.
An alarm activates the output. There are no warnings.
An alarm or warning activates the output.
The torque limit set in parameter 4-16 Torque Limit Motor Mode or parameter 4-17 Torque Limit
Generator Mode has been exceeded.
The motor current is outside the range set in parameter 4-18 Current Limit.
The motor current is lower than set in parameter 4-50 Warning Curent Low.
The motor current is higher than set in parameter 4-51 Warning Current High.
The output frequency is outside the frequency range set in parameter 4-52 Warning Speed Low
and parameter 4-53 Warning Speed High.
Output speed is lower than the setting in parameter 4-52 Warning Speed Low.
The output speed is higher than the setting in parameter 4-53 Warning Speed High.
Parameter Descriptions
Setup: All setups
Change during operation: True
