VLT® AutomationDrive EZ FC 321
Programming Guide
Option Name
[0]* Input
[1] Output
Parameter 5-02 Terminal 29 Mode
Table 280: Parameter 5-02 Terminal 29 Mode
5-02 Terminal 29 Mode
Default value: [0] Input
Conversion index: –
Option Name
[0]* Input
[1] Output

4.6.2 5-1* Digital Inputs

The digital inputs are used for selecting various functions in the drive. Refer to
digital inputs.
Functions in function group 1 have higher priority than functions in function group 2.
Table 281: Function Groups
Group Functions
1 Reset, coast stop, reset, and coast stop, quick stop, DC brake, stop, and the [Off] key.
2 Start, latched start, reversing, start reversing, jog, and freeze output.
Table 282: Digital Input Functions and Terminals
Digital input function
No operation
Reset
Coast inverse
Coast and reset inverse
Quick stop inverse
DC brake inverse
Stop inverse
Start
Latched start
Reversing
Start reversing
Enable start forward
Enable start reverse
142 | Danfoss A/S © 2021.08
Description
Defines terminal 27 as a digital input.
Defines terminal 27 as a digital output.
Parameter type: Option
Data type: Uint8
Description
Defines terminal 29 as a digital input.
Defines terminal 29 as a digital output.
Select
[0]
[1]
[2]
[3]
[4]
[5]
[6]
[8]
[9]
[10]
[11]
[12]
[13]
Parameter Descriptions
Setup: All setups
Change during operation: True
Table 282 for functions which can be assigned to
Terminal
All, terminal 32, 33
All
All, terminal 27
All
All
All
All
All, terminal 18
All
All, terminal 19
All
All
All
AU373327181955en-000101 / 130R1208
