VLT® AutomationDrive EZ FC 321
Programming Guide
Parameter 1-05 Local Mode Configuration
Table 65: Parameter 1-05 Local Mode Configuration
1-05 Local Mode Configuration
Default value: [2] As mode par. 1-00
Conversion index: –
Select which application configuration mode (parameter 1-00 Configuration Mode), that is application control principle, to use when
a local (LCP) reference is active. A local reference can be active only when parameter 3-13 Reference Site is set to [0] Linked to Hand/
Auto or [2] Local. By default the local reference is active in hand-on mode only.
Option Name
[0] Speed open loop
[1] Speed closed loop
[2]* As mode par. 1-00
[4] Positioning
Parameter 1-06 Clockwise Direction
Table 66: Parameter 1-06 Clockwise Direction
1-06 Clockwise Direction
Default value: [0] Normal
Conversion index: –
This parameter defines the term clockwise corresponding to the LCP direction arrow. Used for easy change of direction of shaft
rotation without swapping motor wires.
Option Name Description
[0]* Normal The motor shaft turns in clockwise direction when the drive is connected U⇒U, V⇒V, and W⇒W to the
motor.
[1] Inverse The motor shaft turns in counterclockwise direction when the drive is connected U⇒U, V⇒V, and W⇒W
to the motor.
[2] Inverse all
Parameter 1-07 Motor Angle Offset Adjust
Table 67: Parameter 1-07 Motor Angle Offset Adjust
1-07 Motor Angle Offset Adjust
Default value: [0] Manual
Conversion index: –
Op- Name Description
tion
[0]* Manual The functionality of this option depends on the type of the feedback device. This option sets the drive to
use the motor angle offset entered in parameter 1-41 Motor Angle Offset, if an absolute feedback device is
60 | Danfoss A/S © 2021.08
Parameter type: Option
Data type: Uint8
Description
Allows up to 160% overtorque.
Parameter type: Option
Data type: Uint8
N O T I C E
Parameter type: Option
Data type: Uint8
Parameter Descriptions
Setup: All setups
Change during operation: True
Setup: All setups
Change during operation: False
Setup: All setups
Change during operation: False
AU373327181955en-000101 / 130R1208
