VLT® AutomationDrive EZ FC 321
Programming Guide
Parameter 30-05 Wobble Jump Frequency [%]
Table 698: Parameter 30-05 Wobble Jump Frequency [%]
30-05 Wobble Jump Frequency [%]
Default Value: 0%
Conversion Index: 0
The jump frequency can also be expressed as a percentage of the center frequency. The function is the same as for parameter 30-04
Wobble Jump Frequency [Hz].
Parameter 30-06 Wobble Jump Time
Table 699: Parameter 30-06 Wobble Jump Time
30-06 Wobble Jump Time
Default Value: Size related
Conversion Index: -3
This parameter determines the slope of the jump ramp at the maximum and minimum wobble frequency.
Parameter 30-07 Wobble Sequence Time
Table 700: Parameter 30-07 Wobble Sequence Time
30-07 Wobble Sequence Time
Default Value: 10 s
Conversion Index: -1
This parameter determines the wobble sequence period. This parameter can only be changed in stop mode.
Wobble time = t + t
up down
Parameter 30-09 Wobble Random Function
Table 701: Parameter 30-09 Wobble Random Function
30-09 Wobble Random Function
Default Value: [0] Off
Conversion Index: -
Option
[0]*
[1]
Parameter 30-10 Wobble Ratio
Table 702: Parameter 30-10 Wobble Ratio
30-10 Wobble Ratio
Default Value: 1
Conversion Index: -1
If the ratio 0.1 is selected: t
down
Center frequency
Use parameter group 3-1* References to set the center frequency.
336 | Danfoss A/S © 2021.08
Parameter Type: Range, 0 - 100 %
Data Type: Uint8
Parameter Type: Range, 0.005 - 5.000 s
Data Type: Uint16
Parameter Type: Range, 1 - 1000 s
Data Type: Uint16
Parameter Type: Option
Data Type: Uint8
Name
Off
On
Parameter Type: Range, 0.1 - 10
Data Type: Uint8
is 10 times greater than t . If the ratio 10 is selected: t
up
Setup: All set-ups
Change during operation: True
Setup: All set-ups
Change during operation: True
Setup: All set-ups
Change during operation: True
Setup: All set-ups
Change during operation: True
Description
Setup: All set-ups
Change during operation: True
is 10 times greater than t
up
AU373327181955en-000101 / 130R1208
Parameter Descriptions
.
down
