VLT® AutomationDrive EZ FC 321
Programming Guide
Op- Name Description
tion
• Encoder/Resolver resolution/poles low
• Encoder/Resolver resolution/poles high
Parameter 1-41 Motor Angle Offset is automatically set when using PM motor and absolute encoder or re-
solver.
[7] Enable in- Use this option to ramp up in the mode as specified in parameter 1-01 Motor Control Principle. Measured
ertia run
inertia is set in parameter 1-69 System Inertia and parameter 7-08 Speed PID Feed Forward Factor is set to
90%.
Parameter 1-48 d-axis Inductance Sat. Point
Table 101: Parameter 1-48 d-axis Inductance Sat. Point
1-48 d-axis Inductance Sat. Point
Default value: Size related
Conversion index: 0
Run an AMA to set the value of this parameter. Edit the value manually only when the application requires a value other than
determined by AMA.
Select the d-axis inductance saturation point. The drive uses this value to optimize the performance of SynRM motors. Select the
value that matches the point where the inductance equals the mean value of parameter 1-37 d-axis Inductance (Ld) and parameter
1-44 d-axis Inductance Sat. (LdSat), as percentage of nominal current.
Parameter 1-49 q-axis Inductance Sat. Point
Table 102: Parameter 1-49 q-axis Inductance Sat. Point
1-49 q-axis Inductance Sat. Point
Default value: Size related
Conversion index: 0
Run an AMA to set the value of this parameter. Edit the value manually only when the application requires a value other than
determined by AMA.
Enter the q-axis inductance saturation point. The drive uses this value to optimize the performance of IPM motors. Select the value
that matches the point where the inductance equals the average value of parameter 1-38 q-axis Inductance (Lq) and parameter 1-45
q-axis Inductance Sat. (LqSat), as a percentage of nominal current.

4.2.6 1-5* Load Indep. Setting

Parameter 1-50 Motor Magnetization at Zero Speed
Table 103: Parameter 1-50 Motor Magnetization at Zero Speed
1-50 Motor Magnetization at Zero Speed
Default value: 100%
Conversion index: 0
76 | Danfoss A/S © 2021.08
Parameter type: Range, 1 - 500%
Data type: Int16
N O T I C E
Parameter type: Range, 0 - 200%
Data type: Uint16
N O T I C E
Parameter type: Range, 0 - 300%
Data type: Uint16
Parameter Descriptions
Setup: All setups
Change during operation: True
Setup: All setups
Change during operation: False
Setup: All setups
Change during operation: True
AU373327181955en-000101 / 130R1208
