VLT® AutomationDrive EZ FC 321
Programming Guide
Option
[4]
[5]
[6]
Parameter 1-95 Thermistor Sensor Type
Table 139: Parameter 1-95 Thermistor Sensor Type
1-95 Thermistor Sensor Type
Default value: [0] KTY Sensor 1
Conversion index: –
Select the used type of thermistor sensor.
Option Name
[0]* KTY sensor 1
[1] KTY sensor 2
[2] KTY sensor 3
[3] Pt1000
[4] Ni1000 (6178 ppm/K)
[5] Ni1000-LG (TC5)
Parameter 1-96 Thermistor Sensor Resource
Table 140: Parameter 1-96 Thermistor Sensor Resource
1-96 Thermistor Sensor Resource
Default value: [0] None
Conversion index: –
Selecting analog input terminal 54 to be used as thermistor sensor input. Terminal 54 cannot be selected as thermistor source if
otherwise used as reference (see parameter 3-15 Reference Resource 1 to parameter 3-17 Reference Resource 3).
Connection of thermistor sensor between terminals 54 and 55 (GND).
Option
[0]*
[2]
Danfoss A/S © 2021.08
Name
Digital input 19
Digital input 32
Digital input 33
Parameter type: Option
Data type: Uint8
Description
1 kΩ at 100 °C (212 °F).
1 kΩ at 25 °C (77 °F).
2 kΩ at 25 °C (77 °F).
Examples:
•
•
Parameter type: Option
Data type: Uint8
N O T I C E
Name
None
Analog input 54
Description
Setup: All setups
Change during operation: True
Siemens LG-Ni1000
Tasseron RTD Ni1000-TC5 1000 Ohm
Setup: All setups
Change during operation: True
Description
Parameter Descriptions
AU373327181955en-000101 / 130R1208 | 91
