Option Name
[115] Logic rule 5
[120] SL time-out 0
[121] SL time-out 1
[122] SL time-out 2
[123] SL time-out 3
[124] SL time-out 4
[125] SL time-out 5
[126] SL time-out 6
[127] SL time-out 7
[130] Digital input DI18
[131] Digital input DI19
[132] Digital input DI27
[133] Digital input DI29
[134] Digital input DI32
[135] Digital input DI33
[150] SL digital output A
[151] SL digital output B
[152] SL digital output C
[153] SL digital output D
[154] SL digital output E
[155] SL digital output F
[160] Relay 1
[161] Relay 2
[162] Relay 3
[163] Relay 4
[164] Relay 5
[165] Relay 6
[166] Relay 7
[167] Relay 8
[168] Relay 9
[180] Local reference ac-
tive
238 | Danfoss A/S © 2021.08
Description
The result of logic rule 5.
The result of the SLC timer 0.
The result of the SLC timer 1.
The result of the SLC timer 2.
The result of the SLC timer 3.
The result of the SLC timer 4.
The result of the SLC timer 5.
The result of the SLC timer 6.
The result of the SLC timer 7.
Digital input 18 (high=true).
Digital input 19 (high=true).
Digital input 27 (high=true).
Digital input 29 (high=true)
Digital input 32 (high=true).
Digital input 33 (high=true).
Use the result of the SLC output A.
Use the result of the SLC output B.
Use the result of the SLC output C.
Use the result of the SLC output D.
Use the result of the SLC output E.
Use the result of the SLC output F.
Relay 1 is active.
Relay 2 is active.
Active when parameter 3-13 Reference Site is [2] Local or when parameter 3-13 Reference Site is
[0] Linked to hand/auto, at the same time as the LCP is in hand-on mode.
