VLT® AutomationDrive EZ FC 321
Programming Guide
Option Name Description
[3] Option A
[30] External can
[35] Option A fast Not applicable for current release.
[37] Option C0 fast The reference is transferred faster and without jitter, which ensures more stability and dynamic con-
trol. Furthermore, all other references are ignored, which means that the drive is controlled by the C-
option reference only.
Parameter 8-03 Control Word Timeout Time
Table 411: 8-03 Control Word Timeout Time
8-03 Control Word Timeout Time
Default value: 1 s
Conversion index: -1
Enter the maximum time expected to pass between the reception of 2 consecutive telegrams. If this time is exceeded, it indicates
that the serial communication has stopped. The function selected in parameter 8-04 Control Word Timeout Function is then carried
out. A valid control word triggers the timeout counter.
Parameter 8-04 Control Word Timeout Function
Table 412: Parameter 8-04 Control Word Timeout Function
8-04 Control Word Timeout Function
Default value: Size related
Conversion index: –
Select the timeout function. The timeout function activates when the control word fails to be updated within the time period speci-
fied in parameter 8-03 Control Word Timeout Time.
To change the setup after a timeout, configure as follows:
-
1. Set parameter 0-10 Active Set-up to [9] Multi setup.
-
2. Select the relevant link in parameter 0-12 This Set-up Linked to.
Option Name Description
[0] Off Resumes control via fieldbus (fieldbus or standard), using the most recent control word.
[1] Freeze output Freezes output frequency until communication resumes.
[2] Stop Stops with auto restart when communication resumes.
[3] Jogging Runs the motor at jog frequency until communication resumes.
[4] Max. speed Runs the motor at maximum frequency until communication resumes.
[5] Stop and trip Stops the motor, then resets the drive to restart:
•
•
•
204 | Danfoss A/S © 2021.08
Parameter type: Range, 0.1 - 18000 s
Data type: Uint32
Parameter type: Option
Data type: Uint8
N O T I C E
Via the fieldbus.
Via [Reset].
Via a digital input.
Parameter Descriptions
Setup: 1 setup
Change during operation: True
Setup: 1 setup
Change during operation: True
AU373327181955en-000101 / 130R1208
