VLT® AutomationDrive EZ FC 321
Programming Guide
Option Name
[17] Analog input AICCT
[18] Pulse input FI29
[19] Pulse input FI33
[20] Alarm number
[21] Warning number
[22] Analog input X30/11
[23] Analog input X30/12
[30] Counter A
[31] Counter B
[32] Process PID error
[33] Process PID Output
[34] Analog input X48/2
[35] Temp input X48/4
[36] Temp input X48/7
[37] Temp input X48/10
[39] Safe opt. speed error
[43] Analog input X49/3
[45] Analog input X49/5
[50] FALSE
[51] TRUE
[52] Control ready
[53] Drive ready
[54] Running
[55] Reversing
[56] In range
[60] On reference
[61] Below reference, low
[62] Above ref, high
[65] Torque limit
236 | Danfoss A/S © 2021.08
Description
Value is in [°]. AICCT us control card temperature.
The value is in %.
The value is in %.
The number or registered alarms
Value of the PID error (parameter 18-90 Process PID Error).
Value of the PID output (parameter 18-91 Process PID Output).
Use to enter the fixed value False in the comparator.
Use to enter True in the comparator.
The control board receives supply voltage.
The drive is ready for operation and applies a signal on the control board.
The motor runs.
The output is active when the drive runs counterclockwise (the logical product of the status
bits running AND reverse).
The motor runs within the programmed current and speed ranges set in parameter 4-50 Warn-
ing Current Low to parameter 4-53 Warning Speed High.
The motor runs on reference.
The motor runs at a reference which is less than the value in parameter 4-54 Warning Reference
Low.
The motor runs at a reference which exceeds the value in parameter 4-55 Warning Reference
High.
The torque exceeds the value in parameter 4-16 Torque Limit Motor Mode or parameter 4-17 Tor-
que Limit Generator Mode.
Parameter Descriptions
