VLT® AutomationDrive EZ FC 321
Programming Guide
Option Name
[71] Start timer 4
[72] Start timer 5
[73] Start timer 6
[74] Start timer 7

4.13.6 13-9* User-defined Alerts and Readouts

Parameters in this group allow the configuration of application-specific messages, warnings, and alarms. Use the following parame-
ters to configure the drive to show a message and perform an action when a specific event occurs:
•
Parameter 13-90 Alert Trigger – the event that triggers the user-defined action and message.
•
Parameter 13-91 Alert Action – the action that the drive performs when the event defined in parameter 13-90 Alert Trigger occurs.
•
Parameter 13-92 Alert Text – the text that the drive shows in the display when the event defined in parameter 13-90 Alert Trigger
occurs.
For example, consider the following use case: If there is an active signal on digital input 32, the drive shows the message Valve 5
open and ramps down to a stop. To achieve this configuration, make the following settings:
• Parameter 13-90 Alert Trigger = [37] Digital input DI32.
• Parameter 13-91 Alert Action = [5] Stop & warning.
•
Parameter 13-92 Alert Text = Valve 5 open.
Parameter 13-90 Alert Trigger
Table 469: Parameter 13-90 Alert Trigger
13-90 Alert Trigger
Default Value: [0] False
Conversion Index: -
Select the event that triggers the user-defined action and message.
Option
[0]*
[1]
[18]
[22]
[23]
[24]
[25]
[26]
[27]
[28]
[29]
[30]
[31]
Danfoss A/S © 2021.08
Description
Starts timer 4, see parameter 13-20 SL Controller Timer for further description.
Starts timer 5, see parameter 13-20 SL Controller Timer for further description.
Starts timer 6, see parameter 13-20 SL Controller Timer for further description.
Starts timer 7, see parameter 13-20 SL Controller Timer for further description.
Parameter Type: Option, Array [10]
Data Type: Uint8
Name
False
True
Reversing
Comparator 0
Comparator 1
Comparator 2
Comparator 3
Logic rule 0
Logic rule 1
Logic rule 2
Logic rule 3
SL time-out 0
SL time-out 1
Parameter Descriptions
Setup: 2 set-ups
Change during operation: True
Description
AU373327181955en-000101 / 130R1208 | 261
